1.Application

AC hi-pot testing is the effective and direct wayto test insulation strength for electrical equipment, apparatus or machines. Itchecks dangerous flaws which assure electrical equipment continuous working.

Typical applications: testing of transformers,switchgear, cables, capacitors, aerial motors platforms, hot sticks bucketbricks, vacuum bottles and other related equipment like vacuum interrupters, blankets,ropes, gloves, hydraulics hose, instruments transformers generators.

2. Features

l   Digital display panel mounted controls& indicators, easy to read.

l   Monitoring high voltage, low voltagecurrent and indicator of zero, power, working start,timing.

l   Over-current protection, zero-startingprotection, sound and light alarm.

l   Continuously variable output from zeroto full voltage.

l   Adjustable over current protection, withtrip levels variable from 10 to 110%.

l   With new type time relay, time range iswider (1S ~ 99H).

l   Using the latest current relay, moreaccurate and reliable.

l   Light weight, small size, easy to move.
