Application:

Series resonance PD test system is used widely in AC voltage withstand, PD test, HV withstand test and fault location during PD test.

The system includes variable HV reactor (inductance). The reactor adjusts inductance according to capacitance of test sample.

Main components:

HV series resonancereactor

Excitingtransformer

HV filter

High voltage filterwith inductance

Contact type voltageregulator

LVfilter

Double shieldedisolation transformer

Water treatment

Digital PDdetector

Intelligent controldesk

HV shielding hall asto technical parameters

Discharging rod 1.5m

installation and commissioning service
